3-Way, Control Valves & Actuators, Globe Valve Assembly
294-06174
Valve assy 3W Mix 6″ 400Cv Eq Pct/Lin Brass Trim Flanged Prop El-Hydrl Act SR
$10,992.70
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 1-1/2-inch stroke. The 3-way, mixing, 6-inch, 400 Cv valve assembly with 1-1/2-inch stroke is ANSI Class 250 and has an equal percentage/linear characteristic, brass trim, and flanged end connections.
