2-Way, Control Valves & Actuators, Globe Valve Assembly
294-06154
Valve assy 2W NC 6″, 400Cv, Lin, SS Trim Flanged Prop El-Hydraul Act SR
$12,152.20
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 1-1/2-inch stroke. The 2-way, normally closed, 6-inch, 400 Cv valve assembly with 1-1/2-inch stroke is ANSI Class 250 and has a linear characteristic, stainless steel trim, and flanged end connections.
