2-Way, Control Valves & Actuators, Globe Valve Assembly
294-06053
Valve assy Hi Temp 2W NC 5″ 250Cv Lin SS Trim Flng Prop El-Hydraul Act SR
$9,620.17
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 1-1/2-inch stroke. The 2-way, normally closed, 5-inch, 250 Cv valve assembly with 1-1/2-inch stroke is ANSI Class 125 and has a linear characteristic, stainless steel trim, high temp packing, and flanged end connections.
