2-Way, Control Valves & Actuators, Globe Valve Assembly
294-05962
Valve assy 2W NO, 4″ 160Cv Eq Pct SS Trim Flanged Prop El-Hydraul Act SR
$8,751.12
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 1-1/2-inch stroke. The 2-way, normally open, 4-inch, 160 Cv valve assembly with 1-1/2-inch stroke is ANSI Class 125 and has an equal percentage characteristic, stainless steel trim, and flanged end connections.
