2-Way, Control Valves & Actuators, Globe Valve Assembly
291-03170
Valve assy 2W NO, 2″ 40Cv Eq Pct Brass Trim Prop Internal Thread x Internal Thread, El-Hydraul Act SR
$4,820.43
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 3/4-inch stroke. The 2-way, normally open, 2-inch, 40 Cv valve assembly is ANSI Class 250 and has an equal percentage characteristic, brass trim, and Internal Thread x Internal Thread end connections.
