2-Way, Control Valves & Actuators, Globe Valve Assembly
291-03080
Valve assy 2W NC 2″, 40Cv, Lin, SS Trim Hi Temp Pkg Prop Internal Thread x Internal Thread, El-Hydraul Act SR
$5,589.68
Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator with 3/4-inch stroke. The 2-way, normally closed, 2-inch, 40 Cv valve assembly is ANSI Class 250 and has a linear characteristic, stainless steel trim, high temp packing, and Internal Thread x Internal Thread end connections.
