2-Way, Control Valves & Actuators, Globe Valve Assembly
290-05990
Valve assy 2W NC 2-1/2″ 63Cv Eq Pct Brass Trim Flanged float El-Hydrl Act NSR
$4,440.08
Flowrite 599 Series Valve Assembly features a floating control, non-spring return, 24 Vac electro-mechanical actuator with 3/4-inch stroke. The 2-way, normally closed, 2-1/2-inch, 63 Cv valve assembly with 3/4-inch stroke is ANSI Class 125 and has an equal percentage characteristic, brass trim, and flanged end connections.
