3-Way, Control Valves & Actuators, Globe Valve Assembly
283-06171
Valve assy 3W Mix 3″ 100Cv Eq Pct/Lin Brass Trim Flanged 8″ Pneu Act w/ pos
$3,584.81
Flowrite 599 Series Valve Assembly features a 8-inch pneumatic actuator with factory-mounted positioner and 5 psi span. The 3-way, mixing, 3-inch, 100 Cv valve assembly with 3/4-inch stroke is ANSI Class 250 and has an equal percentage/linear characteristic, brass trim, and flanged end connections.
